earth leakage circuit breaker-ag旗舰厅首页

product application: distribution protection, equipment protection, motor starting and protection

number of poles: 3p, 4p

applicable category: a

rated current (in): 63a-630a

rated operating voltage (ue):ac400v

rated insulation voltage (ui): ac800v

rated impulse withstand voltage (uimp): 8kv

tripping sensitivity (iδn): 100ma, 300ma, 500ma

rated residual markng and breaking capacity (iδm): 12.5ka

type of tripping unit: thermomagnetic

residual current protection release: electronic type

rated residual current tripping characteristics: ac type

release time: adjustable

breaking ability:

ac400v, icu=50ka, ics=35ka

conform to the standard: iec/en60947-2 gb/t14048.2

certificate: ccc ce cb
