product application: distribution protection, equipment protection, motor starting and protection

number of poles: 3p, 4p

applicable category: a

rated current (in): 63a-630a

rated operate voltage (ue):ac400v/ac690v

rated insulation voltage (ui): ac800v

rated impulse withstand voltage (uimp): 8kv

type of tripping unit: thermomagnetic

ambient temperature: -5℃ ~ 55℃

breaking capacity (ac400v):

l:icu=35ka, ac400v, ics=100%icu

m:icu=50ka, ac400v, ics=100%icu

h:icu=65ka, ac400v, ics=100%icu

breaking capacity (ac690v):

m/h:icu=10ka, ics=100%icu

m/h:icu=15ka, ics=100%icu in=630a

conform to the standard: iec/en60947-2   gb/t14048.2

certificate: ccc ce cb
